Industrial-grade embedded computer (PT-ECT5800) with Intel i5-6500 processor, 4GB DDR4, 500GB SATA storage, 10 serial ports, dual Gigabit Ethernet, and 2-channel video capture. Paired with PT-TLC-N-1 lane controller providing 16 isolated digital I/O channels, 13–16 relay outputs, and 8–16 analog inputs with 2500V DC isolation.
| Parameter | PT-ECT5800 (IPC) | PT-TLC-N-1 (Controller) |
|---|---|---|
| Processor | Intel i5-6500 | — |
| Memory / Storage | DDR4 4GB + 500GB SATA | — |
| Ethernet | 2× RJ45 Gigabit | — |
| Serial Ports | 10 (2 onboard + 8 RS232) | — |
| Video | 2-channel capture | — |
| Expansion | 3× PCI + 2× ISA | — |
| Power | 200–240VAC | 185–240VAC |
| Digital I/O | PCL-724 (24ch) + PCL-725 (8ch relay + 8ch input) | 16 DI + 16 DO |
| Low Voltage Out | — | 5–24VDC |
| Low Voltage In | — | 12–24VDC |
| High Voltage Out | — | 185–240VAC |
| Relay Output | — | 13–16 ch, >100M cycles |
| Analog Input | — | 8–16 ch, opto-isolated |
| Isolation | — | 2500V DC |
| Housing | — | Carbon steel / galvanized / aluminum alloy |
| Protection / Temp | IP65, -40°C~+70°C | -20°C~+55°C |
