Highway toll lane automatic card issuing and collection module. Supports continuous and single-card dispensing modes. Features anti-jam card transport mechanism, empty-bin alarm, and reliable pickup of worn cards. Modular design for easy maintenance. ISO7816 & ISO14443A compliant.
| Parameter | Specification |
|---|---|
| Model | PT-CD1200 |
| Power | AC220V±15%, 300mA |
| Card Type | Logic encrypted / dual-interface CPU |
| IC Standards | ISO7816, ISO14443A |
| Transaction Time | ≤250ms (dual-interface CPU) |
| Card Interface | ≤100mm |
| Communication | RS232, USB2.0 (optional), 9.6–115.2kbps |
| SDK | DOS/WIN32 API DLL |
| Antenna Housing | PC/ABS, dark blue/black, IP62 |
| Host Housing | Carbon steel, gray/black |
| Operating Temp | -25°C to +75°C |
| Installation | Desktop or outdoor wall-mount |
Contact us for pricing, volume discounts, and delivery timelines.
Request a Quote
