PLC variable-frequency controlled motor with smooth start/stop and adjustable speed. Rated for 5 million+ cycles, 7×24 continuous operation, IP65 protection, -40°C to +80°C wide-temperature range. Available in three speed grades: 0.7s, 0.9s, and 1.5s.
| Parameter | DL-07-B-R | DL-09-B-R |
|---|---|---|
| Open / Close Time | 0.7s | 0.9s |
| Boom Arm Material | Aluminum alloy or carbon fiber (selectable) | |
| Arm Length | 3.0m | |
| Motor Power | 180W | |
| Torque | 30N·m | 20N·m |
| Noise | ≤60db | |
| Power Supply | AC220V±15%, 50Hz | |
| Operating Temperature | -40°C to +80°C | |
| Protection Rating | IP65 | |
Contact us for pricing, volume discounts, and delivery timelines.
Request a Quote
